Powered by HONDA GX35 Popular New Design Earth Drilling Machine

* Main characteristic : Best-selling style / light weight
* Popular package way : Sets package in one carton
-----1 PCS Earth auger machine
-----1 PCS Spring snubber
-----Each pcs of φ100/150/200mm Earth auger bits
* Professional earth auger bits :
* Mid-range earth auger bits
* Economical earth auger bits
  • HY-GD35-802
Powered by HONDA GX35 ENGINE , 1 person operate EARTH AUGER MACHINE Basic info
Popular , Suitable for 1 person operate model ,HONDA GX35engine Earth auger .  φ25mm tube to make  half oval form handle, use luxury with automatic reset switch & safty arm on  right hand ,  Also the width of the handle is suitable for human mechanics, easy to control. The most popular package way is Earth auger with manual , tool kits and other attached accessories of the earth auger, packaged in one carton/ color box . Each pcs auger bit pakcage by each carton . and the second package way is one machine with each pcs of φ 100,150,200mm auger bit , 1 pcs spring snubber , 1 pcs 500mm extender package in one carton .
Certificate : EAP EURO-V  CE  EMC  ISO9001-2015
Full 360° "any-side-up" operationHandle design: V & Rectangle form to surround engine and gear case
Engine Type: Air-cooled 4-stroke OHCTrigger : (Optional )
Bore x Stroke:39 mm x 30 mm* Simple type with safty arm
Displacement:35.8 cm3* luxury with automatic reset switch & safty arm   (Bisc)
Net Power Output*:1.3 hp (1.0 kW) @ 7,000 rpmVibration reduction system:1 pcs rubber & 1 pcs metal
Net Torque:1.2 lb-ft (1.6 Nm) @ 5,500 rpmTransmission: Gear case  (Optional )
PTO Shaft Rotation:Counterclockwise (from PTO shaft side)*( 2 stages / Model - GC03-2012 )  (Bisc)
Compression Ratio:8.0:1*( 2 stages / Model - GC01-2007 )
Carburetor:Diaphragm-type (overflow return)Gear wheel metrial :20CrMnTi (High temperature carburizing)
Ignition System:Transistorized magnetoGear wheel structure : Helical (Rounded corner)
Starting System:RecoilMain gear wheel contact with output shaft : Spline
Lubrication System:Crankcase pressure–drivenOutput rate: 29:1  (Basic)   /   10:1  / 5:1
Governor System:NAOutput shaft type :  (Optional )
Air Cleaner:Semi-dry* Cylinder φ20mm (Basic) / Cylinder φ22mm / Spline / Other size
Oil Capacity:3.4 US oz (100cc)Max drive ability : ≤ φ 200mm  auger bit
Fuel:Unleaded 86 octane or higherRecommend drive :≤φ 150mm auger bit
Fuel Tank Capacity:0.67 U.S. qt (.63 liter)Auger bit size :  φ40/60/80/100/150/200/250mm
Others info
G.W/N.W :11.03/9.42  kgPackage size : 44X39.5X32CM (Basic)
HS code :8467890000Package way : Color box/ Carton (Basic) / with auger bits for sets by carton
Production time : 65-70 daysShipment port : NINGBO / SHANGHAI
1. Marked as (Basic) in the technical parameters is completely consistent with the product picture.
2. Marker as (Optional) . buyer can according to actually need to choose
This machine Max drive ability : ≤ φ 250mm  auger bit , but we recommend drive :≤φ 200 mm auger bit . Becasue of  there are more diffirent model auger bits can match with this machine. so please check Auger bit in our website to choose the ideal model and size .  then let us know , we will make offer

Wellcome to contact us to talk about more detials , Such as OEM , ODM and so on
